Tuck medium and lightweight stuff onto these DIY garage ceiling storage shelves. The shelves are designed to fit into that unused space above the garage doors (you need 16 inches of clearance to fit a shelf and standard 12-1/2 inch high plastic bins). However, you can adjust the shelf height and put them anywhere. The only limitation is weight. We designed this 4 x 6-foot shelf to hold about 160 lbs., a load that typical ceiling framing can safely support. It’s best to save the shelf for “deep storage,” using labeled bins with lids, because you’ll need a stepladder to reach stuff.
First, find which way the joists run, then plan to hang one shelf support from three adjacent joists. Our joists are 24-inches apart; if yours are spaced at 16-inches, skip one intermediate joist. We built ours to hold plastic bins, but if you put loose stuff up there, add 1×4 sides to keep things from falling off. Assemble the 2x4s as shown , using five-inch corner braces and 1/4-inch x 1-inch hex head lag screws (drill pilot holes first).
Now attach the corner braces on both ends of a shelf support to the center of a joist/truss by drilling pilot holes and using 1/4-inch x 2-inch hex head lag screws. The only challenge is finding the center of joists through a drywall ceiling (if your ceiling is finished) to attach the shelf supports. Tap a small nail through the drywall until you locate both edges of the joist. Measure to find the center of the adjacent joists, and measure to keep the three supports in alignment with one another. Finish the shelf unit by attaching a 3/8-inch x 4-foot x 6-foot plywood floor. You should also check out how to DIY garage cabinets to make more space for storage.
Editor’s Tip: Organizing a garage isn’t a one-size-fits-all project, so we’ve compiled some of our best garage storage ideas. Check out these tips to find ways to make your garage more organized and better to use.
2/4
Family handyman
DIY Garage Hoist
Hanging bikes by one or both wheels on bicycle storage hooks is the quickest and cheapest way to get them off the floor and out of the way. But the hooks won’t always work if you you have a tall garage ceiling or your bike, or e-bike, is too heavy to lift easily . Then the best solution is a convenient garage pulley system that allows you to quickly and easily raise the bike out of the way. We couldn’t design a system much cheaper or better than a purchased system like the Leisure Sports 1-Bike Hoist.
It can lift up to 75 lbs. with its quality mechanical system of pulleys and hooks, and its dual safety design (locking mechanism and rope tie-down cleat) keeps the bike secure. Attach the garage bike storage pulley system brackets to a ceiling joist with wood screws. Position the hooks the same distance apart as the distance from the handlebar to the seat rear. Choose a location that’s convenient yet doesn’t interfere with vehicles or people since the bike will hang down about four feet from the ceiling. If the joists aren’t spaced just right, lag-screw 2x4s to them and then screw the brackets to the 2x4s.
