New TSI Calls - Documentation for BMC AMI DevX Code Pipeline 22.01
Daniel Cobb
There are three new TSI calls available to use in custom Deploy code:
- DPLYPRTI, LIST – List Deploy Part Instance Log Entries
- DPLYPRTI, ADD – Add Deploy Part Instance Log Entry
- DPLYPRTI, CLEANUP – Clean Up Deploy Part Instance Log Entry
DPLYPRTI LIST
This call can be made at some point during the Promotion process (usually in the Set Post Exit) to list all the Target runtime members and libraries that have been deployed to by the Task being promoted. It details all the Deploy Part Instances that have been deployed for that Task from an Application Stream Level in the Code Pipeline lifecycle.
Table-DPLYPRTI LIST Input Fields describes the input and Table-DPLYPRTI LIST Output Fields describes the output fields.
DPLYPRTI LIST Input Fields
Input Field | Description |
|---|---|
TASKIDX,LENGTH=12 | Task ID in hex format |
APPLID,LENGTH=8 | The Application Level in the Code Pipeline Lifecycle where Deploys are initiated |
SUBAPPL,LENGTH=8 | |
STRMNAME,LENGTH=8 | |
LCLVL,LENGTH=4 |
DPLYPRTI LIST Output Fields
Output Field | Description |
|---|---|
DPRTIID,FORMAT=INTEGER,TYPE=KEY | Deploy Part Instance ID |
DPARTID,FORMAT=INTEGER | Deploy Part ID |
DPRTINAM,LENGTH=128 | Deploy Part Instance name |
DPTYPE,LENGTH=8 | Deploy Type |
PARTTYPE,LENGTH=8 | Part Type |
PARTCLAS,LENGTH=4 | Part Class |
PARTNAME,LENGTH=64 | Part Name |
TASKID,LENGTH=6,FORMAT=BINARY | Task ID |
CMPNID,LENGTH=6,FORMAT=BINARY | Component ID |
CMPVID,FORMAT=SMALLINT | Component VID |
DREQID,FORMAT=INTEGER | Deploy Request ID |
PKGID,FORMAT=SMALLINT | Deploy Package ID |
ITEMID,FORMAT=SMALLINT | Deploy Item ID |
SYSTNAME,LENGTH=8 | Deploy System Name |
DPENV,LENGTH=8 | Deploy Environment |
SUBENV,LENGTH=4 | Deploy Sub-Environment |
STORTYPE,LENGTH=4 | Storage Type |
STORNAME,LENGTH=100 | Storage Name |
STORUSGE,LENGTH=1 | Storage Usage |
CTSRVRNM,LENGTH=8 | CT Server Name |
ACTIDTTM,LENGTH=26 | Deploy Log Entry Timestamp |
DPLYPRTI ADD
This new Code Pipeline call will add a Deploy Part Instance Log Entry. It is not required when the Deploy Implementation Type has been set to C (the Copy to the Target is performed internally by Code Pipeline ), because the Deploy Logging happens automatically. It is only required when the ITEM, GET call is being used to copy to the Target. In this situation, Deploy Logging must be requested manually using this new DPLYPRTI, ADD call.
The following table describes the input fields.
DPLYPRTI ADD Input Fields
Input Field | Description |
|---|---|
DPRTINAM,LENGTH=128 | Deploy Part Instance Name (optional), defaults to Deploy Part Name if not provided. |
DIDREQID,FORMAT=INTEGER,VNAME=DREQID | Deploy Request ID |
DIPKGID,FORMAT=SMALLINT,VNAME=PKGID | Deploy Package ID |
DIITEMID,FORMAT=SMALLINT,VNAME=ITEMID | Deploy Item ID |
DISYSTNM,LENGTH=8,VNAME=SYSTNAME | Deploy System Name |
DISTORTP,LENGTH=4,VNAME=STORTYPE | Deploy Part Instance Storage Type, Name and Usage. If these fields aren’t supplied on input, they are looked up from the Deploy Logical Storage Group configuration definition. |
DISTORNM,LENGTH=100,VNAME=STORNAME | |
DISTORUS,LENGTH=1,VNAME=STORUSGE |
DPLYPRTI CLEANUP
This new Code Pipeline call can be used when deleting members from the Target runtime libraries. It tracks this event by updating the current Deploy Part Instance Log Entry to become inactive.
The following table describes the input fields.
DPLYPRTI CLEANUP Input Fields
Input Field | Description |
|---|---|
DPRTIID,FORMAT=INTEGER | Deploy Part Instance ID |
Sample Code
The code in the following figure shows an example Clean Up stub in the Set Post Exit. In the standard Code Pipeline delivered sample it could reside in WZUSETX.
Sample Code – Cleanup_Deploy
Cleanup_deploy:
/* ------------------------------------------------------------------ */
/* This function is called on a promote to cleanup the datasets */
/* deployed at the previous level */
/* ------------------------------------------------------------------ */ call Open_Set "ISPEXEC TBSKIP ASTABLE" tbrc = rc Do While tbrc = 0 DZTABLE = "DZTABLE" taskidx=c2x(taskid) STRMNAME = sxstrm LCLVL = oplvl retc = WZZTSI("DPLYPRTI","LIST") say "DPLYPRTI LIST rc = "retc Address ISPEXEC If retc = 0 then do "TBTOP" DZTABLE Do Until skiprc > 0 "TBSKIP" DZTABLE skiprc = rc If rc = 0 then do say DPRTIID DPRTINAM STORTYPE STORNAME STORUSGE CTSRVRNM delpds = storname delmem = dprtinam Call Delete_Member retcu = WZZTSI("DPLYPRTI","CLEANUP") say "DPLYPRTI CLEANUP rc = "retcu End End "TBEND" DZTABLE End "ISPEXEC TBSKIP ASTABLE" tbrc = rc End
