The Manage Process screen provides a single location to view the list of all processes running in your environment. This includes all the processes running on the servers, mid tiers, and any other environment where armonitor is present.

Use this screen to:

Required permissions

You must have either of the following permissions to access the Manage process screen:

• AR System Administrator
• AR System Configuration Administrator
• Integration Administrator
• Email Administrator

Considerations

• (Windows) You cannot add an external Windows service such as Tomcat.exe, Email Engine, and Flashboard by using the Manage Process screen.

• (Linux) Email Engine and Flashboard processes are considered as processes and are a part of the armonitor.conf file. Therefore, these processes are listed in the Manage Process screen.

• You cannot delete a process command that you have already added.


  Note

  You can delete the process command only from the armonitor.cfg (armonitor.conf) file. You need to restart the AR System services after deleting a particular process.

• A fully qualified server name is displayed only for the AR System server. However, a fully qualified server name is not displayed for mid tier (File Deployer process) and Smart IT (File Deployer process).

• You can disable the Execute Operation button on the Manage Process screen by setting the Disable-Manage-Process-Operation property in ar.cfg to true. This restricts any random operation on the processes and enables you to only view the processes and their status.

To monitor the processes

Select an environment within the server group. Select from the following options:

When you select an option, all processes running in the selected environment are displayed in the table. Additional configuration details are displayed when you select a row in the table.

Important

When you select plug-in related process except for the native plug-in server, additional configuration information displays the Plugin Server Configuration form. You must select the specific plug-in instance to view additional configuration details.

To start, stop, or restart a process

1. Select an environment within the server group. Select from the following options:

   Option	Description
   All	Lists processes of all the components in a server group where the armonitor is running. This includes all hosts.
   Host	Lists processes from a specific host environment that you select from the drop-down list. This shows the processes on all armonitors running on the selected host.
   Type	Lists process for a specific component type that you select from the drop-down list. Component types include: ARServer Midtier SmartIT
   Name	Lists processes from a specific armonitor instance that you select from the drop-down list. This shows processes from a single server, midtier and, SmartIT instance within the server group.

2. In the Operations field, perform an operation for the process identified. Select from the following options:

   Option	Description
   Stop	Stops the selected process.
   Start	Starts the selected process.
   Restart	Restarts (stops and then starts) the selected process.
   Refresh	Reloads the configuration and detailed data for the selected process.

3. Select an operation, and click the Execute Operation  button.

To manage server configuration during runtime

1. Select an environment within the server group. Select from the following options:

   Option	Description
   All	Lists processes of all the components in a server group where the armonitor is running. This includes all hosts.
   Host	Lists processes from a specific host environment that you select from the drop-down list. This shows the processes on all armonitors running on the selected host.
   Type	Lists process for a specific component type that you select from the drop-down list. Component types include: ARServer Midtier SmartIT
   Name	Lists processes from a specific armonitor instance that you select from the drop-down list. This shows processes from a single server, midtier and, SmartIT instance within the server group.

2. In the Operations field, perform an operation for the process identified. Select from the following options:

   Option	Description
   Update	Updates the command in the Command field for the selected process.
   Add	Enables adding a new process to armonitor. Important: You cannot add process with the same command or parameter that is already registered in armonitor.

3. Select an operation, and click the Execute Operation  button.

Related topic

Configuring and monitoring AR System server groups
