If you want to consume web services over SSL or with client certificates, add the Java keystore options in the arserver.config(arserverd.conf) file.

Self-signed certificates or certificates signed by CAs that are not trusted by clients and servers causes maintenance tasks. Using Well known certificate authorities lowers the number of manual tasks and integration disruptions.
If you want to use certificates that are not trusted, make sure to check your internal procedures with the security team in your organization to prevent importing certificates in the future.

When you create a dedicated keystore without using Java cacerts (jre/lib/security/cacerts), an SSL handshake error might occur while consuming external web services on HTTPS. To overcome this  issue, you must import all Java cacerts content into the keystore/trustore.

Refer to the following example:

keytool -v -importkeystore -srckeystore /opt/jdk1.8.0_112/jre/lib/security/cacerts -srcstoretype JKS -destkeystore /opt/bmc/ars/certificatestore.jks -deststoretype JKS -srcstorepass changeit -deststorepass password

You must add only the signed certificate. Use the truststore parameter to point to your file.

For one way SSL, add the following Java keystore options in the arserver.config(arserverd.conf) file:

jvm.option.XX=-Djavax.net.ssl.trustStore=<pathToTrustStore>
jvm.option.XX+1=-Djavax.net.ssl.trustStorePassword=<password>
jvm.option.XX+2=-Djavax.net.ssl.keyStoreType=<keystore Type>

For example:

jvm.option.XX=-Djavax.net.ssl.trustStore=/opt/Java/<Java_Home_Folder>/lib/security/cacerts
jvm.option.XX+1=-Djavax.net.ssl.trustStorePassword=****
jvm.option.XX+2=-Djavax.net.ssl.trustStoreType=JKS

 Refer to the following example if you are not using Java Cacerts for the AR System server process.

jvm.option.XX=-Djavax.net.ssl.trustStore=/opt/bmc/arsystem/conf/certificates.p12
jvm.option.XX+1=-Djavax.net.ssl.trustStorePassword=****
jvm.option.XX+2=-Djavax.net.ssl.trustStoreType=pkcs12

If you want to use similar certificates for other processes such as JAVA Plug-in server, update the armonitor.conf file. Refer to the following example for Java Plug-in server:

/usr/java/default/<Java_Home_Folder>/bin/java -Djavax.net.ssl.keyStore=/opt/bmc/arsystem/conf/certificates.jks -Djavax.net.ssl.keyStorePassword=*** -Djavax.net.ssl.keyStoreType=pkcs12 -Djavax.net.ssl.trustStore=/opt/bmc/arsystem/conf/certificates.p12 -Djavax.net.ssl.trustStorePassword=*** -Djavax.net.ssl.trustStoreType=pkcs12 -Xmx512m -classpath /opt/bmc/arsystem/pluginsvr:/opt/bmc/arsystem/pluginsvr/arpluginsvr91_build001.jar:/opt/bmc/arsystem/approval/bin/armaskingImpl91_build001.jar:/opt/bmc/arsystem/api/lib/arcmnapp91_build001.jar com.bmc.arsys.pluginsvr.ARPluginServerMain -x onbmc-s -i /opt/bmc/arsystem -alias javapluginserver

Refer to the following example for the developerstudio.ini file:

-vmargs
-Djavax.net.ssl.trustStore=/opt/bmc/arsystem/conf/certificates.p12
-Djavax.net.ssl.trustStorePassword=****
-Djavax.net.ssl.trustStoreType=pkcs12

For two way SSL, add the following Java keystore options in the arserver.config(arserverd.conf) file:

jvm.option.XX=-Djavax.net.ssl.keyStore=<path to keyStoreType file>
jvm.option.XX+1=-Djavax.net.ssl.keyStorePassword=*****
jvm.option.XX+2=-Djavax.net.ssl.trustStore=<pathToTrustStore>
jvm.option.XX+3=-Djavax.net.ssl.trustStorePassword=<password>
jvm.option.XX+4=-Djavax.net.ssl.keyStoreType=<keyStore Type>
jvm.option.XX+5=-Djavax.net.ssl.trustStoreType=<TrustStore Type>

For example:

jvm.option.XX=-Djavax.net.ssl.keyStore=/opt/bmc/arsystem/conf/certificates.jks
jvm.option.XX+1=-Djavax.net.ssl.keyStorePassword=*****
jvm.option.XX+2=-Djavax.net.ssl.trustStore=/opt/bmc/arsystem/conf/certificates.p12
jvm.option.XX+3=-Djavax.net.ssl.trustStorePassword=****
jvm.option.XX+4=-Djavax.net.ssl.keyStoreType=JKS
jvm.option.XX+5=-Djavax.net.ssl.trustStoreType=pkcs12

Note

You must start the jvm.option.XX sequence after the last jvm.option in the arserver.config(arserverd.conf) file.

If the arserver.config(arserverd.config) file has jvm.option.19 as last jvm option, add the jvm options starting from jvm.option.20.

The following sample code illustrates jvm.option example:

$stringEscapeUtils.escapeHtml($body)

For SSL support, you must add the jvm options starting from 19 (any other number in the sequence is not initiated on the actual service) as shown in the following example code snippet:

jvm.option.19=-Djavax.net.ssl.keyStore=/opt/bmc/arsystem/conf/certificates.jks
jvm.option.20=-Djavax.net.ssl.keyStorePassword=*****
jvm.option.21=-Djavax.net.ssl.trustStore=/opt/bmc/arsystem/conf/certificates.p12
jvm.option.22=-Djavax.net.ssl.trustStorePassword=****
jvm.option.23=-Djavax.net.ssl.keyStoreType=JKS
jvm.option.24=-Djavax.net.ssl.trustStoreType=pkcs12

Restart the AR System server after all the configurations are complete.
